Today, modern, sustainable architecture is about much more than maximum energy efficiency through the best possible U values. Contemporary aluminium façade systems also feature a slimline appearance, high-quality design and the perfect integration of functional units combined with optimum performance, for example, for insert units. Schüco architects and planners develop innovative designs, allowing them to deliver tested, reliable systems as well as unique solutions tailored to individual projects.

오늘날, 현대적이고 지속 가능한 프로파일 아키텍처는 가능한 최고의 열관류율 값을 통한 최대 에너지 효율을 가능하게 합니다. 현대적인 알루미늄 파사드 시스템은 슬림한 외관, 고품질 디자인, 기능성 유닛의 완벽한 통합과 최적 성능을 특징으로 합니다. 슈코 건축가와 기획자는 혁신적인 디자인을 개발하여 개별 프로젝트에 맞춘 고유한 솔루션 뿐만 아니라 테스트되고 신뢰할 수 있는 시스템을 제공합니다.

FWS50.SI 상품 이미지FWS50.SI
FWS35PD.SI 상품 이미지FWS35PD.SI
FWS50.SI
FWS50.SI 상품 이미지
Size
System Basic Depth : 85 - 255 mm
Maximum Weight : 10800kg
Glass Thickness : 24 - 86 mm
Thermal
Sound Insulation
48dB
Opening Type
Corner
Fix
Side Hung
Skylight
조합가능 Type
Window
Door
Slide
Uf value of frame
1.5 W/(m2 . K)
Min. Face with
50mm
Max.glass/
panelthickness
62mm
Max. weight
1080kg
Air permeability
AE
Watertightness
RE 1200
Impact resistance
I5 / E5
Burglar resistance
Up to RC3
Suitable for
safety Barrier
Yes
Bullet resistance
Up to FB 4
FWS35PD.SI
FWS35PD.SI 상품 이미지
Size
System Basic Depth : 65 - 150 mm
Maximum Weight : 400kg
Glass Thickness : 24 - 50 mm
Thermal

28T

47T    (5XTN 145II + 16Ar + 5CL + 16Ar + 5ONEII ) : 0.685W / m2k / 기밀성능 0.00m3 / hm2

Sound Insulation
51dB
Opening Type
Corner
Fix
조합가능 Type
Window
Door
Slide
Uf value of frame
1.4 W/(m2 . K)
Min. Face with
35mm
Max. glass/
panelthickness
50mm
Max. weight
400kg
Air permeability
AE
Watertightness
RE 1200
Impact resistance
I5 / E5
Burglar resistance
Up to RC3
Suitable for safety Barrier
Yes
