Products

window

상품 대표이미지
window

Windows allow you to look outside from within a building. They provide both the right amount of light penetration and a sufficient level of privacy. At the same time, the style of a window is just as important to users as its functionality. Whether it is for a newbuild or a renovation, Schüco windows are available in many basic depths, in a wide range of opening types and with practical comfort components. You'll find the right window for any application – from barrier-free and sound-reducing options through to panorama windows with the narrowest face widths.

창문은 내부 공간에서 외부를 볼 수 있게 하는 건축요소입니다. 이를 통해 적절한 양의 햇빛을 제공함과 동시에 적절한 프라이버시 또한 유지합니다. 창문의 스타일은 기능성만큼이나 사용자에게 중요합니다. 새로운 건물을 위한 것이든, 리모델링을 위한 것이든, 슈코 창문은 다양한 개방 유형과 실용적인 편안한 구성 요소를 가진 많은 옵션을 제공합니다. 베리어 프리, 방음 등 다양한 창문 옵션을 통해 소비자의 니즈를 충족합니다.

AWS75.SI 상품 이미지AWS75.SI
AWS70.HI 상품 이미지AWS70.HI
AWS114 상품 이미지AWS114
AWS75.SI
AWS75.SI 상품 이미지
Size
Vent Width : 470 - 1700mm
Vent Height : 540 - 2500mm
Vent Maximum Weight : 250kg
Glass Thickness : 18-61mm
Thermal

24T

28T

43T   (발급예정)

47T    (5XTN 145II + 16Ar + 5CL + 16Ar + 5PLAONE ) : 0.821W/m2k / 기밀성능 0.00m3 / hm2

Sound Insulation
48dB
Opening Type
Inward Type: Inward Type은 윈도우 도어 제외하고 외부 방충망(슈코제품) 추가가 가능합니다.
Fix / Corner Fix / Tilt and Turn / Side Hung / Window

Door Outward Type: Outward 은 슈코제품으로 방충망 시공이 불가능합니다.
Project Top Hung / Side Hung
System Basic depth
75mm
Min. Face with
91mm
Uf value of frame
0.92 W/(m2 . K)
Max.glass
/panelthickness
61mm
Max. vent width
1700 mm
Max. vent height
2500 mm
Air permeability
Class 4
Watertightness
Class 9A
Burglar resistance
Up to RC3
Wind load resistance
Class C5 / B5
CE marking
Yes
AWS70.HI
AWS70.HI 상품 이미지
Size
Vent Width : 470 - 1700mm
Vent Height : 540 - 2500mm
Vent Maximum Weight : 200kg
Glass Thickness : 18-61mm
Thermal

24T   (발급예정)

28T

47T    (5XTN 145II + 16Ar + 5CL + 16Ar + 5PLAONE ) : 0.870W/m2k / 기밀성능 0.00m3 / hm2

Sound Insulation
48dB
Opening Type
Inward Outward
Min. Face with
91mm
Uf value of frame
1.5 W/(m2 . K)
Max.glass
/panel thickness
62mm
Max. vent width
1700 mm
Max. vent height
2500 mm
Air permeability
Class 4
Watertightness
Class 9A
Burglar resistance
Up to RC3
Wind load resistance
Class C5 / B5
AWS114
AWS114 상품 이미지

* AWS114 : 복층 유리만 지원합니다.

Size
Vent Width : 650 - 2700mm
Vent Height : 650 - 3600mm
Vent Maximum Weight : 250kg
Glass Thickness : 24-42mm
Thermal

24T   (시험성적서 없음)

32T    (8SR P100 - 15 + 16Ar + 8P - 15 ) : 1.440W/m2k / 기밀성능 0.00m3 / hm2 (FWS60 기준 시험성적서 입니다)

Sound Insulation
48dB
Opening Type
Project Top Hung (Tip Tronic 가능)
Parallel-Opening (아직 국내 지원 불투명)
Uf value of frame
1.8 W/(m2 . K)
Min. Face with
52mm
Min. -max. system
Basic depth
77…121mm
Max.glass
/panel thickness
44mm
Max. Weight
250kg
Surface finishes
Powder, Anodised, Paint
Air permeability
Class 4
Max. Sound reduction
Index Rwp
43db
Watertightness
E 1200
Impact resistance
Class 4
Burglar resistance
Up to RC3
